ENGINE
-
DESIGN
1-cylinder, 4-stroke engine
-
DISPLACEMENT
690 cm³
-
BORE
102 mm
-
STROKE
84.5 mm
-
POWER IN KW
49 kW
-
STARTER
Electric starter
-
LUBRICATION
Forced oil lubrication with 2 oil pumps
-
TRANSMISSION
6-speed
-
PRIMARY DRIVE
36:79
-
SECONDARY GEAR RATIO
16:42
-
COOLING
Liquid cooled
-
CLUTCH
APTC(TM) slipper clutch, hydraulically actuated
-
EMS
Keihin EMS with RBW, twin ignition
CHASSIS
-
FRAME DESIGN
Chromium-Molybdenum steel trellis frame, powder coated
-
FRONT SUSPENSION
WP USD Ø 48 mm
-
REAR SUSPENSION
WP shock absorber with Pro-Lever linkage
-
SUSPENSION TRAVEL (FRONT)
215 mm
-
SUSPENSION TRAVEL (REAR)
250 mm
-
FRONT BRAKE
Brembo four-piston radial fixed calliper, brake disc
-
REAR BRAKE
Brembo single-piston floating calliper, brake disc
-
FRONT BRAKE DISC DIAMETER
320 mm
-
REAR BRAKE DISC DIAMETER
240 mm
-
ABS
Bosch 9M+ two-channel ABS (disengageable, optional Supermoto mode)
-
CHAIN
X-Ring 5/8 x 1/4″
-
STEERING HEAD ANGLE
63 °
-
WHEELBASE
1480 ± 15 mm
-
GROUND CLEARANCE
270 mm
-
SEAT HEIGHT
890 mm
-
TANK CAPACITY (APPROX.)
12 l
-
DRY WEIGHT
144 kg
