ENGINE
-
DESIGN
2-cylinder, 4-stroke, V 75°
-
DISPLACEMENT
1301 cm³
-
BORE
108 mm
-
STROKE
71 mm
-
POWER IN KW
127 kW
-
STARTER
Electric starter
-
LUBRICATION
Forced oil lubrication with 3 oil pumps
-
TRANSMISSION
6-speed
-
PRIMARY DRIVE
40:79
-
SECONDARY GEAR RATIO
17:38
-
COOLING
Liquid cooled
-
CLUTCH
PASC (TM) slipper clutch, hydraulically actuated
-
EMS
Keihin EMS with RBW, twin ignition
CHASSIS
-
FRAME DESIGN
Chromium-Molybdenum steel trellis frame, powder coated
-
FRONT SUSPENSION
WP USD Ø 48 mm
-
REAR SUSPENSION
WP monoshock
-
SUSPENSION TRAVEL (FRONT)
125 mm
-
SUSPENSION TRAVEL (REAR)
156 mm
-
FRONT BRAKE
2 x Brembo monoblock four-piston radial fixed calliper, brake discs, floating
-
REAR BRAKE
Brembo twin-piston fixed calliper, brake disc
-
FRONT BRAKE DISC DIAMETER
320 mm
-
REAR BRAKE DISC DIAMETER
240 mm
-
ABS
Bosch 9M+ two-channel ABS (incl. Supermoto mode, disengageable)
-
CHAIN
X-Ring 5/8 x 5/16″
-
STEERING HEAD ANGLE
65.1 °
-
WHEELBASE
1482 ± 15 mm
-
GROUND CLEARANCE
140 mm
-
SEAT HEIGHT
835 mm
-
TANK CAPACITY (APPROX.)
18 l
-
DRY WEIGHT
189 kg
