ENGINE
-
DESIGN
2-cylinder, 4-stroke, V 75°
-
DISPLACEMENT
1301 cm³
-
BORE
108 mm
-
STROKE
71 mm
-
POWER IN KW
118 kW
-
STARTER
Electric starter
-
LUBRICATION
Forced oil lubrication with 3 oil pumps
-
TRANSMISSION
6-speed
-
PRIMARY DRIVE
40:76
-
SECONDARY GEAR RATIO
17:42
-
COOLING
Liquid cooled
-
CLUTCH
PASC (TM) slipper clutch, hydraulically actuated
-
EMS
Keihin EMS with RBW and cruise control, double ignition
CHASSIS
-
FRAME DESIGN
Chromium-Molybdenum steel trellis frame, powder coated
-
FRONT SUSPENSION
WP Semi-active suspension USD Ø 48 mm
-
REAR SUSPENSION
WP Semi-active suspension monoshock
-
SUSPENSION TRAVEL (FRONT)
200 mm
-
SUSPENSION TRAVEL (REAR)
200 mm
-
FRONT BRAKE
2 x Brembo four-piston radial fixed calliper, brake discs, floating
-
REAR BRAKE
Brembo twin-piston fixed calliper, brake disc
-
FRONT BRAKE DISC DIAMETER
320 mm
-
REAR BRAKE DISC DIAMETER
267 mm
-
ABS
Bosch 9ME combined ABS (incl. cornering ABS and offroad mode, disengageable)
-
CHAIN
X-Ring 5/8 x 5/16″
-
STEERING HEAD ANGLE
64 °
-
WHEELBASE
1560 ± 15 mm
-
GROUND CLEARANCE
220 mm
-
SEAT HEIGHT
860 mm
-
TANK CAPACITY (APPROX.)
30 l
-
DRY WEIGHT
222 kg
